From raw displacement to deterministic phase separation: The HPDD family in three integrated modules.
Industrial processing, from high-TDS brine valorization and mineral harvesting to circular commodities like recovered Carbon Black (rCB), frequently hits identical roadblocks: parasitic conversion losses, mechanical complexity, and uncontrolled particle agglomeration.
We solve this by structuring our processing architecture around three complementary, high-stiffness modules:
1. HPDD (Hydro Puls Direct-Drive) – The Energy Heart
The HPDD provides the foundational process force, hydraulic displacement, and thermal energy directly, eliminating fragile crankshafts entirely. Crucially, it metered-delivers the required nitrogen and water streams into the process boundary. It acts as the rigid, oil-free driver maintaining dynamic control over the upstream envelope.
2. ACR (Acoustic Cavitation Reactor) – The Multi-Application Intensifier
What makes the HPDD platform versatile across different sectors? The ACR. By generating high-frequency acoustic shockwaves, it delivers extreme shear, homogeneous crystal nucleation, and complete particle deagglomeration. The internal fluid kinetics of the ACR are slightly tuned depending on the feed stream (viscous bitterns, fluid mixtures, or pulverized vapor streams), unlocking an extensive range of industrial use cases.
3. VCD (Vertical Convective Decoupler) – The Media Separator
Once particles are deagglomerated and chemically active, the stream enters the VCD. This vertical convective column operates at 1 bar to decouple distinct media phases. While vapors and volatile fractions rise convectively and react in-flight, bone-dry, high-purity solids and crystalline fractions precipitate out cleanly.
The architecture:
• Power, Nitrogen & Water Feedstock (HPDD)
• Kinetic Shear & Deagglomeration (ACR)
• Multi-Media Phase Decoupling (VCD)
One modular, direct-drive process train operating under an ironclad closed mass balance (ΔMass = 0.000 kg).
